EN 10016-2 Non-alloy steel rod
EN 10016-2 specifies the technical delivery conditions for non-alloy steel rods intended for subsequent processing by cold drawing or cold rolling. These rods are primarily used in the manufacturing of precision components, including fasteners, automotive parts, and engineering applications requiring high dimensional accuracy and surface finish.
Key Features:
- Excellent machinability and formability
- Consistent chemical composition for reliable performance
- Suitable for cold drawing and cold rolling applications
- Enhanced surface finish and dimensional control
EN 10016-2 Chemical Composition (% by weight)
| Grade | C (max) | Mn | P (max) | S (max) | Si (max) |
|---|---|---|---|---|---|
| C10E | 0.08–0.13 | 0.30–0.60 | 0.035 | 0.035 | 0.40 |
| C15E | 0.12–0.18 | 0.30–0.60 | 0.035 | 0.035 | 0.40 |
| C22E | 0.18–0.24 | 0.50–0.80 | 0.035 | 0.035 | 0.40 |
| C35E | 0.32–0.39 | 0.50–0.80 | 0.035 | 0.035 | 0.40 |
| C45E | 0.42–0.50 | 0.50–0.80 | 0.035 | 0.035 | 0.40 |
EN 10016-2 Mechanical Properties
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation A5 (%) | Brinell Hardness (HB) |
|---|---|---|---|---|
| C10E | 340–470 | 200–300 | ≥28 | ~105–140 |
| C15E | 370–500 | 220–320 | ≥26 | ~110–150 |
| C22E | 430–560 | 250–350 | ≥23 | ~130–170 |
| C35E | 540–690 | 300–400 | ≥20 | ~150–190 |
| C45E | 590–740 | 330–430 | ≥18 | ~170–210 |
Applications:
- Automotive components
- Mechanical engineering
- Precision parts manufacturing
- Fastener production
