Description
Tube to Male Pipe Adapter (Male Connector)
A Tube to Male Pipe Adapter is an instrumentation fitting designed to connect a compression tube end to a female threaded pipe port (NPT, BSPT, BSPP, Metric).
It ensures a leak-tight, vibration-resistant, high-pressure connection, widely used in process industries.
Key Features
- Leak-proof double ferrule sealing
- High corrosion resistance
- Excellent vibration resistance
- Suitable for high-pressure systems
- Precision CNC machined
- Easy installation & reusability
Standard Sizes of Tube to Male Pipe Adapter
Tube OD Sizes (Compression Side)
| Tube OD (Inch) | Tube OD (mm) |
|---|---|
| 1/16″ | 1.6 mm |
| 1/8″ | 3.2 mm |
| 1/4″ | 6.35 mm |
| 3/8″ | 9.52 mm |
| 1/2″ | 12.7 mm |
| 3/4″ | 19.05 mm |
| 1″ | 25.4 mm |
| 1 1/4″ | 31.75 mm |
| 1 1/2″ | 38.1 mm |
| 2″ | 50.8 mm |
Male Thread Sizes (Pipe Side)
| Thread Type | Available Sizes |
|---|---|
| NPT | 1/16″ to 2″ |
| BSPT | 1/8″ to 2″ |
| BSPP | 1/8″ to 2″ |
| Metric | M10 to M33 |
Thread Standards:
- ASME B1.20.1 (NPT)
- ISO 7-1 (BSPT)
- ISO 228 (BSPP)
Applications
- Oil & Gas Instrumentation Lines
- Chemical Processing Plants
- Power Generation
- Hydraulic & Pneumatic Systems
- Refineries & Petrochemical Plants
