EN 10268 Cold Rolled Steel
EN 10268 is a European standard that specifies cold rolled steel flat products with high yield strength for cold forming. These steels are designed to offer improved mechanical properties while still retaining good formability, making them ideal for structural and automotive applications.
Key Features
- High yield strength
- Cold-rolled precision
- Suitable for cold forming processes
- Improved mechanical performance over EN 10130
- Better surface finish and dimensional tolerance
Common Grades
| Grade | Description |
|---|---|
| HC260Y | High yield, good formability |
| HC300Y | Higher strength, moderate formability |
| HC340Y | Enhanced strength, suitable for bending |
| HC380LA | High strength, low alloy |
| HC420LA | Higher strength, low alloy |
| HC460LA | Extra high strength, low alloy |
Equivalent Standards
| Standard | Equivalent Grades |
|---|---|
| ASTM A1008 | HSLAS Grades |
| JIS G3135 | SPFC440, SPFC590 |
| ISO 3574 | CR220, CR250, CR330 |
EN 10268 Chemical Composition
| Grade | C (max %) | Si (max %) | Mn (max %) | P (max %) | S (max %) | Al (min %) | Nb (max %) | Ti (max %) |
| HC260LA | 0.1 | 0.5 | 0.6 | 0.025 | 0.025 | 0.015 | 0.09 | 0.15 |
| HC300LA | 0.1 | 0.5 | 1 | 0.025 | 0.025 | 0.015 | 0.09 | 0.15 |
| HC340LA | 0.1 | 0.5 | 1 | 0.025 | 0.025 | 0.015 | 0.09 | 0.15 |
| HC380LA | 0.1 | 0.5 | 1.4 | 0.025 | 0.025 | 0.015 | 0.09 | 0.15 |
| HC420LA | 0.1 | 0.5 | 1.6 | 0.025 | 0.025 | 0.015 | 0.09 | 0.15 |
| HC460LA | 0.16 | 0.5 | 1.6 | 0.025 | 0.025 | 0.015 | 0.09 | 0.15 |
| HC500LA | 0.16 | 0.5 | 1.6 | 0.025 | 0.025 | 0.015 | 0.09 | 0.15 |
EN 10268 Mechanical Properties
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation A80 (min %) |
| HC260LA | 260 – 330 | 350 – 430 | 26 |
| HC300LA | 300 – 380 | 380 – 480 | 23 |
| HC340LA | 340 – 420 | 410 – 510 | 21 |
| HC380LA | 380 – 470 | 440 – 560 | 19 |
| HC420LA | 420 – 520 | 470 – 590 | 17 |
| HC460LA | 460 – 560 | 500 – 640 | 15 |
| HC500LA | 500 – 620 | 530 – 690 | 13 |
Product Forms:
- Cold Rolled Coils
- Cut-to-Length Sheets
- Slit Coils
- Blanks
Applications:
- Automotive structural components
- Reinforcements and safety parts
- Metal furniture and enclosures
- Domestic appliances
- Roll forming and press forming parts
